Edelbrock

Cylinderhuvud

The E-Street cylinder heads are designed for 1961-1979 Chrysler 361-440 Wedge engines

Artikelnummer: EDL5090
Inkl. moms29 359,00 kr
Exkl. moms23 487,20 kr
I lager

Mer information


The #5090 E-Street cylinder heads are designed for 1961-1979 Chrysler 361-440 Wedge engines. American made affordable power the combustion chamber improves the combustion process larger than stock intake and exhaust ports move more air.

The Edelbrock #5090 E-Street cylinder heads are designed for use with 1961-1979 Chrysler 361-440 c.i.d. Wedge engine applications. The Edelbrock E-Street cylinder heads offer American made quality and affordable performance. E-Street cylinder heads feature as-cast ports and are designed for entry-level street performance applications operating in the idle-to-5500 rpm range. The modern combustion chamber designs improve the combustion process and larger than stock intake and exhaust ports move more air through your engine for improve efficiency. For use on pre-pollution controlled vehicles only.

Family:E-Street
Series:E-Street
EGR Port:No
Material:Aluminum
Quantity:Set of 2
CNC Ported:No
Grade Type:Performance
Horsepower:400-550 HJ
Seat Angle:Exhaust 45 deg/Intake 45 DD
Valve Angle:15 DD
Camshaft Type:Flat Tappet
Seat Material:Ductile Iron
Deck Thickness:0.625"
Guide Material:Manganese Bronze
Valve Included:Yes
Construction Type:Complete
Push Rod Diameter:(Suggested) 0.375 Inch
Retainer Included:Yes
Head Casting Number:N/A
Valve Stem Diameter:0.3438 Inch
Intake Runner Volume:210 CCM
Exhaust Port Location:Standard
Exhaust Runner Volume:70 CCM
Guide Plates Included:No
Intake Valve Diameter:2.14"
Valve Spring Diameter:1.55 Inch
Exhaust Valve Diameter:1.81"
Valve Springs Included:Yes
Combustion Chamber Volume:75 CCM
Valve Spring Maximum Lift:0.600 Inch
